Design Temperature (℃)

1400

Working Temperature (℃)

50 – 1300

Chamber Dimensions (mm)

300 × 200 × 200 (D × W × H)

Heating Element

Silicon Carbide (SiC) rod

Thermocouple

S-type

Voltage

220V / 1P

Temperature Control Accuracy (℃)

±1

Heating Rate

0 – 30 ℃/min

Maximum Vacuum Level

-0.1 MPa

Furnace Structure

Dual-layer air-cooled structure; surface temperature remains below 50 ℃.

Chamber Material

New high-purity lightweight alumina ceramic fiberboard with high-temperature resistance and excellent thermal insulation.

Temperature Control Mode

Intelligent temperature controller featuring 30-segment programmable PID auto-tuning, automatic heating and cooling, requiring no manual supervision.

Work Gas Support

Inert gases such as Argon (Ar), Nitrogen ($ ext{N}_2$), etc.

Sealing Method

The furnace door features full flat face milling with embedded silicone gasket sealing, offering high airtightness and easy opening/closing.

Temperature Control Safety

Integrated circuit with module control featuring deviation protection, over-temperature protection, thermocouple burnout protection, and over-current protection for stable and safe operation.

Gas Control System

The gas inlet end can be configured with 1 or multiple inlets, each with a ball valve and connected to 1 vacuum gauge. The outlet end includes 1 exhaust port and 1 vacuum port, all equipped with ball valves. Equipped with 1 vacuum pump.

Product Certification

Standard CE Certification; ISO 9001:2015 Quality Management System Certification.
